Straight Blade Die 15 mm
Model 1200-C15 · 15 mm straight cut Fits Desktop Corner Cutter 1200A 15 mm straight slit. Card slots in folders and presentation covers, belt tabs, packaging inserts, cut through a stack in one stroke.
- 15 mm straight slit
- Mounts on the 1200 two-screw plate, same footprint as every die
- Stainless steel, cuts 100 sheets of 80 gsm paper per stroke on the 1200
- Sold as a die on its plate, ready to fit
Specifications
Model 1200-C15
| Model | 1200-C15 |
|---|---|
| Profile | Straight slit, 15 mm |
| Fits | Desktop Corner Cutter 1200 |
| Mount | Two-screw plate |
| Cutting capacity | 100 sheets of 80 gsm PPC paper · stack height 10 mm |
| Material | Stainless steel, grey |
| Dimensions | 70 × 20 × 20 mm |
| Net weight | 50 g |
| Origin | Made in Taiwan |
Downloads
Drawing & parts list
1200-C15 drawing (PDF)on request
Dies & parts list (PDF)on request
Need a radius we do not list? Custom die profiles are available for OEM orders.
